CementRaw Materials Handling & Crushing
Apron feeder pan / impact plate (raw material feeding)
Apron feeder carries blasted limestone from primary crushing. Impact load at loading point – Mn liners or AR450 plate overlay. Structural pan: standard cast steel.
Specifications
Material
Cast Steel ASTM A27 / A148 (structural pan); Mn steel or AR450 overlay (wear zones)
Material Class
Cast SteelMn Steel
Applicable Standards
ASTM A27
Service Conditions
impact loading
Common Processes
Sand casting (pans); heat treat
NDT & Inspection
MT; dimensional; VT; hardness (wear zones)
Typical Specs & Notes
Apron feeder carries blasted limestone from primary crushing. Impact load at loading point – Mn liners or AR450 plate overlay. Structural pan: standard cast steel.
